We are able to undertake all aspects of PCB design. Including:
Schematic capture and library creation
All areas of design technology are covered eg
High Speed Digital
Analogue
RF
SMT
MicroVia etc
Using state of the art CAD systems combined with our design engineers in depth knowledge of manufacturing and assembly processes
EMC and signal integrity issues
PCB capability:
| Product Name | Electronics PCB Design |
| Type | Rigid |
| Material | FR4, CEM1, CEM3, High Frequency Board, |
| Layer | 1,2,4,6...20Layer |
| Shape | Retangular, Round, Slots, Cutouts, Complex, Irregular |
| Cutting | Shear, V-score, Tab-routed |
| Board Thickness | 0.2-4mm, regular 1.6mm |
| Copper Thickness | 0.5-4oz, regular 1oz |
| Silk Screen | White, Black, etc. |
| Silk Screen Min Line Width | 0.006" or 0.15mm |
| Min Trace/Gap | 0.1mm or 4mils |
| Min Drill Hole Diameter | 0.01",0.25mm or 10mils |
| Surface Finish | HASL, ENIG, OSP, etc. |
“Emphasis on Quality” At YDY the emphasis has always been on quality, and this is reflected in our production personnel and equipment. Our Design and Production departments operate in the same building and are in constant contact with each other.
Shenzhen Yideyi Technology Co., Ltd is a representation of a dynamic R&D team fully supported by sets of stringent production management and quality assurance systems, comprehensive project management and logistic systems to handle electronic and industrial automation production process with ease. We offer one-stop service ranging from product designing, electronic circuit hardware designing, PCB circuit designing, microcontroller researching and development, PC software programming, product exterior industrial designing, prototype developing, circuit board manufacturing, SMT chip enhancing, DIP welding enhancing and usability testing to aging testing.
We can process prototypes quickly:
YDY keen on establishing partnership with you esteemed company.
FAQ:
Q1. How can we ensure our information should not let third party to see our design?
We are willing to sign NDA effect by customer side local law and promising to keep customers date in high confidential level in all projects.
Q2. How long does it take for PCB and PCBA Quote ?
PCBs quotation within 2 hours can finished the PCBA depend on the components
quantity,if simple, within 6 hours can finished,once complex and more,the 12- 36 hours
can be finished.
Q3. Please note that the following detail will speed up evaluation:
Material:
Board thickness:
Copper thickness:Surface finish:
Solder mask color:
Silkscreen color:
Q4. How about the delivery?
Normally, for sample order, our delivery is about 5 days.For small batch, our delivery is about 7 days.
For mass production batch, our delivery is about 10 days.
But that depends on the real condition when we get your order.
If your order is urgently please contact us directly ,we will priority to deal it and do ourbest to give you satisfied delivery time.
Q5. With payment terms do we accept?
For sample order or small batch, we suggest you to use Pay-pal and Western Union.For mass production batch, we suggest you to use T/T.
Q6. How can we guarantee you receive an good quality product?
For PCB, we will use Flying Probe Test, E-test etc. for it.
For PCBA, we need you to offer us a method or test fixture for the function test.Before that, our inspectors will use microscope and X-ray to check the IC footwelding or bad solder etc.
