Soldering Flex Pcb Through Hole PCB Assembly Routing Military Automotive

Product Categories
Shenzhen Yideyi Technology Limited Company
Contact Now

Soldering Flex Pcb Through Hole PCB Assembly Routing Military Automotive

  • 1
  • 2
  • 3

Brand Name : YDY

Model Number : TP12

Certification : ISO13485, IATF16949, ISO9001,IOS14001

Place of Origin : China

MOQ : 1pcs

Price : $0.1 -$0.3/ 1 piece

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 30000pcs/month

Delivery Time : 1-20 working days

Packaging Details : Vacuum packing or Anti-static package,Outer:export carton or according to the customer's requirement.

Service : One-stop PCB prototype manufacturing, component procurement, full turnkey PCB assembly, and testing service.

Type : Through Hole Pcb Assembly DIP Assembly Technology Military Automotive Pcb Assembly

Color : Green,Customized Color,Blue on your request

Copper thickness : 0.5oz-4oz

Layer : 1~60 layers

Pcb assembly process : SMT THT DIP,DIP. SMT PCB Assembly

Surface finishing : HASL,OSP,ENIG,HASL Lead Free,immersion gold

MOQ : No

Contact Now

Through Hole Pcb Assembly DIP Assembly Technology Military Automotive Pcb Assembly


Why choose YDY for your through-hole PCB assembly services :

We have automated insertion equipment for placing components axially or radially.

We use various such equipment for high-speed installation of through-hole components.

Reflow oven in our facility allows us to fix soldering paste appropriately.

Automated wave soldering system allows us to precisely solder through-hole components.

Advanced aqueous washing system for removing contaminants from the circuit boards.

We use computer-controlled selective soldering machines for reducing errors that may occur during tin-lead or RoHS Through-hole assembly. This helps us reduce errors, as well as the costs of manufacturing.

We provide in-house conformal coating, as well as device programming.

All PCBs are built to ANSI/J-STD-001 and IPC-A-610-D standards.

PCB Manufacture Capacity

Service type Through Hole Pcb Assembly DIP Assembly Technology Military Automotive Pcb Assembly
Material FR-4,FR2.Taconic,Rogers, CEM-1 CEM-3,ceramic , crockery Metal-backed Laminate
Surface Finish HASL(LF), Gold plating, Electroless nickel immersion gold, Immersion Tin, OSP(Entek)
Finish Board Thickness 0.2mm-6.00 mm(8mil-126mil)
Copper Thickness 1/2 oz min;12 oz max
Solder Mask Green/Black/White/Red/Blue/Yellow
Min.Trace Width & Line Spacing 0.075mm/0.1mm(3mil/4mil)
Min.Hole Diameter for CNC Driling 0.1mm(4mil)
Min.Hole Diameter for punching 0.9mm(35mil)
Biggest panel size 610mm*508mm
Hole Positon +/-0.075mm(3mil) CNC Driling
Conductor Width(W)

0.05mm(2mil)or;

+/-20% of original artwork
Hole Diameter(H)

PTH L:+/-0.075mm(3mil);

Non-PTH L:+/-0.05mm(2mil)
Outline Tolerance

0.125mm(5mil) CNC Routing;

+/-0.15mm(6mil) by Punching
Insulation Resistance 10Kohm-20Mohm
Conductivity <50ohm
Test Voltage 10-300V
Panel Size 110×100mm(min);660×600mm(max)
Layer-layer misregistration

4 layers:0.15mm(6mil)max;

6 layers:0.25mm(10mil)max
Min.spacing between hole edge to circuity pqttern of an inner layer 0.25mm(10mil)
Min.spacing between board oulineto circuitry pattern of an inner layer 0.25mm(10mil)
Board thickness tolerance

4 layers:+/-0.13mm(5mil);

6 layers:+/-0.15mm(6mil)
Impedance Control +/-10%

Our Through-hole PCB Assembly Testing and Inspection Capabilities

In-Circuit Testing: This type of testing is conducted for high volume production lines and helps us check every minute soldering and other components in detail.

Automated Optical Inspection: Abbreviated as AOI, these tests are performed to ensure that product is free from soldering, component, and BGA defects.

Automated X-Ray Inspection (AXI): This testing is performed to inspect short fills, short circuits, fills, etc. The mechanical X-ray inspection helps reduce the number of defects and improve the quality of the Through-Hole circuit.

Burn-in Tests: These tests are performed on components to detect their failure or reliability in real environments.



Assisted Visual Inspection: Our experts use a wide range of advanced visual inspection equipment to perform a detailed inspection of soldering and component placement accuracy.

Soldering Flex Pcb Through Hole PCB Assembly Routing Military Automotive

One-stop Turnkey PCB Assembly Manufacturer

We can provide PCB prototypes to high volume assembly services at shorter turnaround times. Our through hole printed circuit board services are designed to provide high-quality products to mission-critical applications to industries such as aerospace, electronics, instrumentation, and military.

Soldering Flex Pcb Through Hole PCB Assembly Routing Military Automotive
